IGBT Defects Control Microfocus X Ray Source Installed on X Ray Detection Machine

  • 1
  • 2
  • 3

Brand Name : Unicomp

Model Number : UNMS-U150B

Certification : CE, FDA

Place of Origin : China

MOQ : 1set

Price : Can be negotiated

Payment Terms : T/T, L/C

Supply Ability : 100 Per Month

Delivery Time : 2 Weeks

Packaging Details : Thick wooden box

Contact Now

Chinese Factory X Ray Source for X Ray Inspection Machine to check IGBT

Key Parameter:

  • Max. Tube Power: 60W

  • Max. Tube Voltage: 150kV

  • Beam Angle: 110±3°

  • Min. Spot Size: ≤7μm

Applications:

  • Integrated Circuit Package

  • EV Battery

  • SMT, PCBA ,Electronic Manufacturing

  • IGBT Substrate / Module

Specifications:

Operating Tube Voltage Range 40-150 kV
Operating Tube Current Range 0-400 μA
Maximum Tube Power 60W
Power Consumption
＜150W
Input Voltage (DC)
48±0.5V
Window Material/Thickness Be/0.51mm
Window Diameter 38mm
Beam Angle 100±3°
Target Material
Tungsten
Weight Approx.15kg
FOD 12±0.5mm
Safty Interlock External Short-circuit
Operating Mode
Continuous
Control Connection Digital Control

X-ray Images:

IGBT Defects Control Microfocus X Ray Source Installed on X Ray Detection MachineIGBT Defects Control Microfocus X Ray Source Installed on X Ray Detection MachineIGBT Defects Control Microfocus X Ray Source Installed on X Ray Detection Machine

Footprint:

IGBT Defects Control Microfocus X Ray Source Installed on X Ray Detection Machine
